Grundfos CUE 3x380-500V IP55 55kW External Frequency Control Module - 500v - Three Phase
Free Delivery Over £50
CUE is a complete range of external frequency converters designed for speed control of a wide range of Grundfos pumps. CUE has a built-in PI controller and offers the same functionality and user-interface as Grundfos E-pumps. CUE solutions can thus be seen as an extension to the E-pump range. By choosing a CUE-solution, you will get the following benefits: Grundfos E-pump functionality and user-interface application- and pump-family-related functions increased comfort compared to fixed-speed pumps very easy installation and commissioning compared to standard frequency converters speed control of pumps up to 250 kW speed control of pumps installed in potentially explosive environments. CUE offers the following inputs and output: RS-485 GENIbus an analog 0-10 V input for external setpoint an analog 0/4-20 mA input for sensor four digital inputs for various functions, for instance external start/stop two signal relays (C/NO/NC). Accessories: Input/output add-on board Provides additional input: one 0/4-20 mA analog input for an additional sensor one 0-20 mA an
CUE is a complete range of external frequency converters designed for speed control of a wide range of Grundfos pumps. CUE has a built-in PI controller and offers the same functionality and user-interface as Grundfos E-pumps. CUE solutions can thus be seen as an extension to the E-pump range. By choosing a CUE-solution, you will get the following benefits:
|
CUE offers the following inputs and output:
|
Accessories:
Input/output add-on board Provides additional input:
|
Motor filters:
For reduction of dU/dt and peak voltages to the motor windings and for reduction of the acoustic noise generated in the motor, a number of motor filters are offered:
|
alog output two inputs for Pt100/Pt1000 temperature sensors, for instance for bearing monitoring. Motor filters: For reduction of dU/dt and peak voltages to the motor windings and
Price | £6,118.50 |
---|---|
Manufacturer | Grundfos |
Warranty | 1 year warranty |
Electrical supply | 500V |
AC Power | Three Phase |
Duty Type | Commercial |
Pump Type | Pump Control Module |
Next Day Delivery | No |
Manufacturers Part Number | 99616773 |
